Description
Single parameter characterisation of the crack/notch tip field using fracture mechanics parameters like K, J or CTOD has been extremely powerful in advancing predictive technologies for critical or sub-critical crack growth. It has also become clear over the last 40 years that single parameter approaches have limitations particularly in dealing with crack growth phenomena arising from crack tip shielding, often resulting from the plastic enclave surrounding a crack. Influences of this enclave on the crack tip stress field ahead of the crack are maximised during cyclic loading. In the case of a parameter like stress intensity factor, K, which characterises the crack tip field via an elastic approximation, it is not surprising that any set of plasticity-induced circumstances which perturb the size of the plastic enclave and its associated strain field lead to predictive difficulties. Over the last 30 years, notable areas of activity related to such difficulties include short cracks, plasticity-induced closure, variable amplitude and multiaxial loading and notch effects. Thus an increasing number of authors and research groups, particularly in Europe, are working on the topic of characterisation of crack tip stresses using more than one fracture mechanics parameter. Attention has been directed, for example, towards incorporating the T-stress into life prediction methods. The T-stress is the second term in a Williams-type expansion of the crack tip stresses and it affects the extent and shape of crack tip plasticity. It would therefore be expected to be influential in plasticity-related crack growth phenomena and a number of publications have demonstrated this to be true. The situation is further complicated where a crack experiences multiaxial loading and Modes II and III fracture mechanics parameters are also necessary. Other research groups have focussed attention on incorporating additional elastic fracture mechanics parameters into crack/notch tip characterisation, which describe the effects of an Eshelby-type ‘plastic inclusion’ on an elastic stress field.
The first highly successful workshop on this topic was held in Forni di Sopra, Udine, Italy in March 2011 and the proceedings were published as a joint-Special Issue of IJFatigue and FFEMS.
Francesco Iacoviello (Università di Cassino e del Lazio Meridionale, Italy)
Neil James (University of Plymouth, United Kingdom)
Pablo Lopez-Crespo (University de Malaga, Spain)
Luca Susmel (University of Sheffield, United Kingdom)
The first highly successful workshop on this topic was held in Forni di Sopra, Udine, Italy in March 2011 and the proceedings were published as a joint-Special Issue of IJFatigue and FFEMS.
Francesco Iacoviello (Università di Cassino e del Lazio Meridionale, Italy)
Neil James (University of Plymouth, United Kingdom)
Pablo Lopez-Crespo (University de Malaga, Spain)
Luca Susmel (University of Sheffield, United Kingdom)
23 Episodes
Reverse
The influence of environmental medias on crack propagation of a structural steel at high and very-high-cycle fatigue (VHCF) regimes is investigated based on the fatigue tests performed in air, water and 3.5% NaCl aqueous solution. Crack propagation mechanisms due to different crack driving forces are investigated in terms of fracture mechanics. A model is proposed to study the relationship between fatigue life, applied stress and material property in different environmental medias, which reflects the variation of fatigue life with the applied stress, grain size, inclusion size and material yield stress in high cycle and VHCF regimes. The model prediction is in good agreement with experimental observations.
Very-High-Cycle-Fatigue regime for metals was considered and mechanisms of the subsurface crack origination were introduced. In many metals first step of crack origination takes place with specific area formation because of material pressing and rotation that directed to transition in any volume to material ultra-high-plasticity with nano-structure appearing. Then by the border of the nano-structure takes place volume rotation and fracture surface creates with spherical particles which usually named Fine-Granular-Area. In another case there takes place First-Smooth-Facet occurring in area of origin due to whirls appearing by the one of the slip systems under discussed the same stress-state conditions. Around Fine-Granular-Area or First-Smooth-Facet there plastic zone appeared and, then, subsurface cracking develops by the same manner as for through cracks. In was discussed quantum-mechanical nature of fatigue crack growth in accordance with Yang’s modulus quantization for low level of deformations. New simply equation was considered for describing subsurface cracking in metals out of Fine-Granular-Area or Fist-Smooth-Facet.
This work presents a novel methodology for characterising fatigue cracks under biaxial conditions. The methodology uses high magnification Digital Image Correlation (DIC) technique for measuring displacement and strain crack-tip fields. By applying micro-speckle pattern on the metal surface it is possible to achieve high magnification for DIC technique. The speckles were created by electro-spray technique. The validity of this novel technique is demonstrated by direct comparison with standard extensometer measurements, under tension-compression and torsion conditions. In order to image the correct region, the notch effect on the fatigue life was also evaluated.
The present authors have previously proposed a novel ‘plastic inclusion’ approach for dealing with the local plasticity which occurs at the tip of a growing fatigue crack. This meso-scale model provides a modified set of crack tip stress intensity factors that include the magnitude of plastic wake-induced crack tip shielding and which have the potential to help resolve some long-standing controversies associated with plasticity-induced closure. The present work extends the CJP model to deal with the case of mixed Mode I and Mode II loading and thus opens up enhanced possibilities for testing it on inclined cracks in metallic specimens. This extension requires the addition of only one new force parameter to the model, i.e. an anti-symmetric shear force on either side of the crack.
This paper analyzes the effects of crack tip plastic strains and compressive residual stresses, created by fatigue pre-cracking, on environmentally assisted cracking of pearlitic steel subjected to localized anodic dissolution and hydrogen assisted fracture. In both situations, cyclic crack tip plasticity improves the behavior of the steel. In the respective cases, the effects are supposed to be due to accelerated local anodic dissolution of the cyclic plastic zone (producing chemical crack blunting) or to the delay of hydrogen entry into the metal caused by residual compressive stresses, thus increasing the fracture load in aggressive environment.
In recent years, the advent of staring array detectors has made Thermoelastic Stress Analysis (TSA) a technique with considerable potential for fatigue and fracture mechanics applications. The technique is non-contacting and provides full field stress maps from the surface of cyclically loaded components. In addition, the technique appears to have a great potential in the evaluation of the effective stress intensity factor range during fatigue since fracture mechanics parameters are derived directly from the temperature changes in the vicinity of the crack tip rather than from remote data. In the current work TSA is presented as a novel methodology for measuring the effective stress intensity factor from the analysis of thermoelastic images. ΔK values inferred using TSA have been employed to estimate an equivalent opening/closing load at different R-ratios in a cracked aluminium 2024 CT specimen. Results have been compared with those obtained using the strain-offset technique showing a good level of agreement.
Crack closure influences fatigue crack growth rate and must be included in the design of components. Plasticity induced crack closure is intimately linked with the crack tip plastic deformation, which becomes residual as the crack propagates. The objective here is to study numerically the effect of crack propagation on crack tip fields. The transient effect observed at the beginning of crack propagation is linked to the hardening behavior of material. The effect of mesh refinement is studied, and a singular behavior is evident, which is explained by the sharp crack associated with mesh topology, composed of a regular pattern of square elements. The plastic zone size measured perpendicularly to crack flank in the residual plastic wake is quantified and compared with literature models. Finally, the removal of material at the first node behind crack tip with load cycling was observed for plane strain state and some hardening models in plane stress state.
Threshold condition and rate of fatigue crack growth in both short and long crack regime appear to be significantly affected by the degree of crack deflection. In the present paper, a theoretical model of a periodically-kinked crack is presented to describe the influence of the degree of crack deflection on the fatigue behavior. The kinking of the crack is due to a periodic self-balanced microstress field having a length scale, d. By correlating the parameter d with a characteristic material length (e.g. average grain size in metals, maximum aggregate dimension in concrete), the possibility of using the present model to describe some experimental findings related to crack size effects in fatigue of materials is explored. Well-known experimental results concerning two different situations (fatigue threshold and fatigue crack growth in the Paris regime) are briefly analysed.
This work presents an in-situ characterisation of crack-tip strain fields following an overload by means of synchrotron X-ray diffraction. The study is made on very fine grained bainitic steel, thus allowing a very high resolution so that small changes occurring around the crack-tip were captured along the crack plane at the mid-thickness of the specimen. We have followed the crack as it grew through the overload location. Once the crack-tip has progressed past the overload event there is strong evidence that the crack faces contact in the region of the overload event (though not in the immediate vicinity of the current locations of the crack tip) at Kmin even when the crack has travelled 1mm beyond the overload location. It was also found that at Kmax the peak tensile strain ahead of the crack-tip decreases soon after the overload is applied and then gradually recovers as the crack grows past the compressive region created by the overload.
According to Gradient Mechanics (GM), stress fields have to be determined by directly incorporating into the stress analysis a length scale which that takes into account the material microstructural features. This peculiar modus operandi results in stress fields in the vicinity of sharp cracks which are no longer singular, even though the assessed material is assumed to obey a linear-elastic constitutive law. Given both the geometry of the cracked component being assessed and the value of the material length scale, the magnitude of the corresponding gradient enriched linear-elastic crack tip stress is then finite and it can be calculated by taking full advantage of those computational methods specifically devised to numerically implement gradient elasticity. In the present investigation, it is first shown that GM’s length scale can directly be estimated from the material ultimate tensile strength and the plane strain fracture toughness through the critical distance value calculated according to the Theory of Critical Distances. Next, by post-processing a large number of experimental results taken from the literature and generated by testing cracked ceramics, it is shown that gradient enriched linear-elastic crack tip stresses can successfully be used to model the transition from the short- to the long-crack regime under Mode I static loading
The paper deals with the three-dimensional nature and the multi-parametric representation of the stress field ahead of cracks and notches of different shape. Finite thickness plates are considered, under different loading conditions. Under certain hypotheses, the three-dimensional governing equations of elasticity can be reduced to a system where a bi-harmonic equation and a harmonic equation have to be simultaneously satisfied. The former provides the solution of the corresponding plane notch problem, the latter provides the solution of the corresponding out-of-plane shear notch problem. The analytical frame is applied to some notched and cracked geometries and its degree of accuracy is discussed comparing theoretical results and numerical data from 3D FE models
This paper presents a numerical method for non-local stress assessment by means of a general FE tool and the local stress field. Unlike usual calculations by means of a numerical PDE solver, a more general numerical integration is used. Different solutions are compared theoretically and numerically by evaluating the results obtained by two different FEM commercial software. The application of the non-local tension field is applied to the strength assessment of notches, welded joints and cracks.
The premature contact of crack surfaces attributable to the near-tip plastic deformations under cyclic loading, which is commonly referred to as plasticity induced crack closure (PICC), has long been focused as supposedly controlling factor of fatigue crack growth (FCG). Nevertheless, when the plane-strain near-tip constraint is approached, PICC lacks of straightforward evidence, so that its significance in FCG, and even the very existence, remain debatable. To add insights into this matter, large-deformation elastoplastic simulations of plane-strain crack under constant amplitude load cycling at different load ranges and ratios, as well as with an overload, have been performed. Modeling visualizes the Laird-Smith conceptual mechanism of FCG by plastic blunting and re-sharpening. Simulation reproduces the experimental trends of FCG concerning the roles of stress intensity factor range and overload, but PICC has never been detected. Near-tip deformation patterns discard the filling-in a crack with material stretched out of the crack plane in the wake behind the tip as supposed PICC origin. Despite the absence of closure, load-deformation curves appear bent, which raises doubts about the trustworthiness of closure assessment from the compliance variation. This demonstrates ambiguities of PICC as a supposedly intrinsic factor of FCG and, by implication, favors the stresses and strains in front of the crack tip as genuine fatigue drivers.
Ductile cast irons (DCIs) are characterized by a wide range of mechanical properties, mainly depending on microstructural factors, as matrix microstructure (characterized by phases volume fraction, grains size and grain distribution), graphite nodules (characterized by size, shape, density and distribution) and defects presence (e.g., porosity, inclusions, etc.). Versatility and higher performances at lower cost if compared to steels with analogous performances are the main DCIs advantages.
In the last years, the role played by graphite nodules was deeply investigated by means of tensile and fatigue tests, performing scanning electron microscope (SEM) observations of specimens lateral surfaces during the tests (“in situ” tests) and identifying different damaging micromechanisms.
In this work, a pearlitic DCIs fatigue resistance is investigated considering both fatigue crack propagation (by means of Compact Type specimens and according to ASTM E399 standard) and overload effects, focusing the interaction between the crack and the investigated DCI microstructure (pearlitic matrix and graphite nodules). On the basis of experimental results, and considering loading conditions and damaging micromechanisms, the applicability of ASTM E399 standard on the characterization of fatigue crack propagation resistance in ferritic DCIs is critically analyzed, mainly focusing the stress intensity factor amplitude role.
Semi–empirical notch sensitivity factors q have been widely used to properly account for notch effects in fatigue design for a long time. However, the intrinsically empirical nature of this old concept can be avoided by modeling it using sound mechanical concepts that properly consider the influence of notch tip stress gradients on the growth behavior of mechanically short cracks. Moreover, this model requires only well-established mechanical properties, as it has no need for data-fitting or similar ill-defined empirical parameters. In this way, the q value can now be calculated considering the characteristics of the notch geometry and of the loading, as well as the basic mechanical properties of the material, such as its fatigue limit and crack propagation threshold, if the problem is fatigue, or its equivalent resistances to crack initiation and to crack propagation under corrosion conditions, if the problem is environmentally assisted or stress corrosion cracking. Predictions based on this purely mechanical model have been validated by proper tests both in the fatigue and in the SCC cases, indicating that notch sensitivity can indeed be treated as a stress analysis problem.
For wedge splitting test specimens, the stress and displacement fields both in the vicinity and also in larger distance from the crack tip are investigated by means of numerical methods. Several variants of boundary conditions were modeled. The stress intensity factor K, T-stress and even higher-order terms of William series were determined and subsequently utilized for analytical approximation of the stress field. A good fit between the analytical and numerical solution in dependence on the distance from the crack tip was shown, compared and discussed. Presented approach is considered as suitable for estimation of the fracture process zone extent in silicate composite materials.
The present paper describes a novel experimental technique recently presented that allows one to study interactions between the crack and microstructural barriers with an unprecedented level of ease and detail. The method consists in increasing the grain size of Al1050 Aluminium alloy until the centimetre scale by applying a series of mechanical and heat treatments. Once the thermo-mechanical treatment is completed and the desired microstructure obtained, a circular notch is machined on each specimen, and the samples are subjected to push-pull fatigue loading. Several combinations of notch and microstructural sizes have been tested. This method provides an easy way to record and analyse the effect of the microstructure upon crack growth rate. It was observed that the space between successive crack-tip arrests correlates well with the material grain size. Another interesting observation is that in the majority of the cases studied the cracks did not initiate at the point of maximum stress concentration. This is surprising since the classical methods of notched fatigue limit analysis clearly indicate the horizontal symmetry axis as the initiation and propagation direction for push-pull loading.
The three dimensional growth of fatigue cracks in samples of nodular graphite cast iron is characterized using laboratory X-ray computed tomography. The cracks grow from laser machined artificial defects, their development is monitored in situ using laboratory X-ray computed tomography (lab. CT) and Digital Volume Correlation (DVC). The combination of both techniques gives access to the 3D displacement field at the tip of the crack (mainly mode I opening).
The concept of ratchetting strain as a crack driving force in controlling crack growth has previously been explored at Portsmouth using numerical approaches for nickel-based superalloys. In this paper, we report the first experimental observations of the near-tip strain evolution as captured by the Digital Image Correlation (DIC) technique on a compact tension specimen of stainless steel 316L. The evolution of the near-tip strains with loading cycles was studied whilst the crack tip was maintained stationary. The strains were monitored over the selected distances from the crack tip for a given number of cycles under an incremental loading regime. The results show that strain ratchetting does occur with load cycling, and is particularly evident close to the crack tip and under higher loads. A finite element model has been developed to simulate the experiments and the simulation results are compared with the DIC measurements.
